His Excellency Al-Attiyah launches the 77 task force - on the road to realising the Vision - Qatar delivering 77 million tonnes of LNG to the world

Doha, Qatar: Aug 30 , 2010: As the State of Qatar moves closer to realizing the Vision of His Highness the Emir, Sheikh Hamad Bin Khalifa Al-Thani, for Qatar to reach a liquefied natural gas production capacity of 77 million tonnes per annum,  by far the largest LNG capacity in the world, His Excellency Deputy Premier and Minister of Energy & Industry and Chairman of Qatar Petroleum, Abdullah Bin Hamad Al-Attiyah, has announced the formation of a multi-company, multi- discipline 77Mta Task Force charged with marking  the achievement of this historic milestone.

His Excellency Al-Attiyah, in delivering the directive said:

With the imminent completion of Qatargas Train 6 and 7 and the earlier completion of RasGas Train 7, we, Qatar, will have an installed capacity of some 77 million tonnes of liquefied natural gas - thus fulfilling His Highnesss vision.  This is a milestone of historic significance for the state of Qatar. Our country will certainly take centre position on the world energy stage as the worlds largest LNG producer. I am very proud of this achievement and look forward to the celebration.

His Excellency added:

Thanks to the far-sighted vision of and the firm commitment from His Highness the Emir, and the continuous support of H.H. Sheikh Tamim Bin Hamad Al-Thani, the Heir Apparent, the country is now at the forefront of the worlds LNG industry. This unparalleled achievement would not have been possible, also, without the strenuous efforts of countless number of people involved in every stage of our ambitious LNG projects. The application of state-of-the-art technology and the introduction of innovative approaches also helped speed up this process.

In addition to His Excellencys formation of the 77Mta Task Force, His Excellency appointed Abdulaziz Al Malki, Director, Office of Deputy Premier, as Chair of the 77 Higher Committee to oversee the plans.

The 77 Higher Committee has representation from the Qatar Petroleum (QP) Group of Companies, namely Qatargas, RasGas and Ras Laffan Industrial City (RLIC) led by QP.  It will be the first time this dynamic group of companies and disciplines will have come together to present such a significant achievement for the State of Qatar.

Work is already underway to ensure that every aspect and milestone, from the conception of His Highnessvision to the present day, is captured in a unique and inspiring way.

Close communication and collaboration has begun with other interested stakeholders, including the offices of the Emiri Diwan and company shareholder representatives, ensuring this significant milestone is captured in a way that has never been seen before.

The central event of the 77 Mta of LNG will take the form of a celebration showing all aspects of the projects, the people and infrastructure which have made this achievement possible.

Mr. AbdulAziz Al Malki added that:

Our combined aim is to put together a unique platform ? and a breathtaking event - which will demonstrate to the world our pride and the recognition of all who have supported Qatar in turning His Highnesss vision into reality

It is anticipated that the 77Mta event will be held on Monday 13 Dec 2010 at Ras Laffan to be shared with a global audience along with the worlds media.

At the national level, Qatar is committed to achieving the goals of the Qatari National Vision 2030.

This Vision identifies the key economic outcomes resulting from the responsible exploration of the nations oil and gas resources.

The 77Mta LNG achievement has certainly been instrumental in forging the Qatari skyline, the infrastructure, Qatars global positioning and providing lasting foundations for the education and the health of the nation as well as addressing issues of environmental well-being.

The 77Mta celebration will, in addition, recognize the need to establish a balance between reserves and production.

Today, as His Excellency Al-Attiyah announces the formation of the 77 Task Force, the first step in the journey of 77Mta has been taken.

Over the next 103 days the community in Qatar and exporting markets will be encouraged to engage, acknowledge and play their part in celebrating the nations LNG achievements.

---

Qatargas operating company limited

Qatargas pioneered the liquefied natural gas (LNG) industry in Qatar. Today, the company is realizing its vision to deliver LNG to customers around the globe from our world-class facilities in Qatar.

Qatargas was
established in 1984 and since that time the Company has progressively established itself as a leading player in the LNG industry.

The company was originally formed to operate
three LNG trains with a design capacity of two million tonnes per annum (mtpa) each. The shareholders in this venture (referred to as Qatargas 1) are Qatar Petroleum, ExxonMobil, Total, Mitsui and Marubeni.

After a successful debottlenecking project completed in 2005, the total production capacity of Qatargas 1 increased to nearly ten mtpa of LNG. Qatargas 1 exports LNG to customers in Japan and Spain under long and mid-term contracts.

Currently the Company is undergoing a period of rapid expansion, which when completed in 2010 will see us exporting 42 mtpa to markets in Europe, Asia and North America.

In 2009, the Company successfully started production from two new 7.8 mtpa mega trains - Train 4 and Train 5. These are the largest LNG trains to ever be built and togerther comprise Qatargas 2.

Qatargas 3 (Train 6) and Qatargas 4 (Train 7) will increase the total number of LNG trains to seven from the existing five.



Qatargas 1 consists of three onshore LNG trains with a total combined capacity of 10 million tonnes per annum (mtpa).

The Qatargas offshore production, separation and treatment facilities on the North Field are located about 80 kilometers North-East of Qatars mainland.

22 production wells have been drilled and completed to supply 1,600 million standard cubic feet (45 million cubic meters) of raw natural gas per day from the fields reservoir, underneath the seabed.

The processed gas is transferred to shore with the associated condensate via a single 32-inch sub-sea pipeline, where it becomes the feedstock for the onshore LNG plant.

The Onshore LNG plant occupies a site within Ras Laffan Industrial City on a plot of land 3.7 square kilometers in area. The onshore plant consists of three LNG trains. Each of the trains is 300 metres long and the trains process the natural gas into the export product known as Liquefied Natural Gas or LNG

Qatargas 1
condensate production is 51,000 barrels per day
1   200320万トン   Qatar Petroleum 65%
ExxonMobil 10%
Total 10%
Mitsui 7.5%
Marubeni 7.5%
2   200320
3   200320
Qatargas 2 4   780   Qatar Petroleum 70%
ExxonMobil 30%
5   780   Qatar Petroleum 65%
ExxonMobil 18.3%
Total 16.7%
Qatargas 3 6   780   Qatar Petroleum 68.5%
ConocoPhillips 30%
Mitsui & Co. Ltd 1.5%
Qatargas 4 7   780   Qatar Petroleum 70%
Royal Dutch Shell 30%
Total     4080
Laffan Refinery

146,000 bspd of
condensate feed stock
    61,000 bpsd of naphtha
52,000 bpsd of kerojet
24,000 bpsd of gasoil
9,000 bpsd of LPG

設備が能力いっぱいで稼動する
際の一日あたり処理量(barrel per stream day
  Qatar Petroleum 51%
ExxonMobil 10%
Total 10%
Idemitsu 10%
Cosmo 10%
Mitsui 4.5%
Marubeni 4.5%

RasGas 12 1999/8 660   Ras Laffan Liquefied Natural Gas
Qatar Petroleum 70%
ExxonMobil
30 %
3 2004/2 470
4 2005/8 470
5 2006/11 470
6 2009/7 780

合計で
110,000 barrels per day of condensate
1.5 Mta of LPG
7 2010/2 780

    3630


The formation of the operating company has several benefits. In addition to efficiently providing services to an increasing number of trains and shareholders, the operating company structure allows the Qatargas projects to achieve maximum synergies. The role of the operating company is that of a service provider with no equity interest.

With its current operations, Qatargas has delivered well over 1700 cargoes as of end 2009. Qatargas is recognized worldwide as a secure and reliable supplier of LNG.

---



RasGas Company Limited

RasGas Company Limited (RasGas) is a Qatari Joint Stock Company established in 2001 by Qatar Petroleum and ExxonMobil who are 70 per cent and 30 per cent shareholders respectively.

RasGas is one of the premier integrated liquefied natural gas (LNG) enterprises in the world. RasGas has developed world class facilities for the extraction, storage, processing and export of LNG and entered into long-term agreements to supply customers around the globe, including Korea, India, Italy, Spain, Taiwan, Belgium and the United States.

RasGas currently operates five LNG trains with 20.7 million tonnes per annum (Mta) of production capacity. It is expected that this production will be in the region of 37 Mta by 2009 with the completion of seven trains.

RasGas acts as the operating company for and on behalf of the Project Owners noted below. Its personnel manage and supervise the design, construction and operation of various facilities under the terms of a Services Agreement for Operation and Maintenancesigned in 2002. The company employs more than 1,400 staff, working on a variety of projects.

In 2003, RasGas was designated to manage and supervise the design, construction and operation of a helium facility on behalf of Ras Laffan, Ras Laffan (II) and Qatargas. The Central Helium Recovery unit (HeRu) project at Ras Laffan extracts helium from RasGas (Ras Laffan and Ras Laffan (II)) and Qatargas (QG 1) LNG trains, and puts Qatar on the map as the provider of 10 per cent of the worlds helium. RasGas has also signed a technical services agreement to manage and supervise activities related to Qatargas (II)s drilling programme in addition to its own drilling programmes.

The Project Owners are:

RAS LAFFAN LIQUEFIED NATURAL GAS COMPA NY LIMITED RAS LAFFAN

Ras Laffan was established in 1993 to produce LNG and related products from its two trains: Trains 1 and 2. The two plants have a combined capacity of 6.6 million tonnes of LNG per annum (Mta) as well as about 45,000 barrels per day (bpd) of condensate. Ras Laffans key customer is Korea Gas Corporation (KOGAS).

RAS LAFFAN LIQUEFIED NATURAL GAS COMPANY LIMITED (II) RAS LAFFAN (II)

Established in 2001 to produce LNG and related products, Ras Laffan (II) owns Trains 3, 4 and 5. Each of these trains has the capacity to produce 4.7 Mta of LNG and about 28,000 bpd of associated condensate. Ras Laffan (II)s key customers are Petronet LNG of India, Edison Gas of Italy, Distrigas of Belgium and Endesa of Spain.

RAS LAFFAN LIQUEFIED NATURAL GAS COMPANY LIMITED (3) RAS LAFFAN (3)

Ras Laffan (3) was formed in 2005 to produce LNG and related products, Ras Laffan (3) owns Trains 6 and 7, which are currently being constructed. Trains 6 and 7 will each have capacity to produce 7.8 Mta of LNG and approximately 50,000 bpd of condensate. Ras Laffan (3)s customers will include the United States and Asian market.

---

Qatar LNGプロジェクト

年産780万トンの世界初・最大規模のLNGプラント(QGX

地域 Qatar 完工年 2009
分野 LNG プラント
種別
LNG Plant
Capacity 7.8mtpa×2 Scope EPC
顧客名 Qatar Liquefied Gas Co., Ltd.(U) 場所 Ras Laffan

カタールガス社向けLNGプラント(第45系列建設)プロジェクト(QGX)はカタール ラスラファン沖のノースフィールドで採掘された 天然ガスを原料とし、2系列のプラントで各々年産780万トンのLNGを製造する世界初・最大規模のビックプロジェクトです。プラントのスケールアップに あたってはあらゆるケースを想定して設計およびシミュレーションを繰り返し、技術課題をクリアしていきました。敷地面積は380,000m2(東 京ドーム約30個分の広さ)、建設に携わった従事者はピーク時で40カ国から、一日あたり約27,000人にも及びます。カタールは「2010年までに年 産7,700万トンのLNGを生産する世界一のLNG生産国となる」ことを目指しており、まさにこの国家的プロジェクトの一翼を担ったのがQGXプロジェ クトです。なお、カタールで千代田が並行して遂行していた他の2つのLNGプロジェクトとともに、カタールLNGプラント建設実績、地球環境への貢献が評 価され、政府(経済産業省、国土交通省、文部科学省、厚生労働省)主催の第3回「ものづくり日本大賞」(海外展開部門)で部門最高位の賞となる経済産業大 臣賞を受賞しました。海外に展開するエンジニアリング業界では初の栄誉となりました。



2018年3月22日  千代田化工建設

ノースフィールド拡張案件(新規液化天然ガスプラント案件)のFEED業務を受注



千代田化工建設は、カタール国国営石油会社であるカタールペトロリアムによって 、同国ラスラファン工業団地内にて計画されているノースフィールド拡張案件(新規液化天然ガスプラント案件)に関する基本設計
(FEED)業務を 遂行するコントラクターに選ばれましたので、お知らせいたします。

本案件は、世界最大の単一ガス田である同国ノースフィールドガス田の南部から新たに生産される日量約46億立方フィートの天然ガスを液化処理し、年産2,300万トンの液化天然ガス(LNG)を追加生産することを
目的としたものです。

昨年7月にQP社が公表の通り、本計画によって同国はLNG生産量を現在の年産7,700万トンから年産1億トンに増産可能となります。

FEED業務の役務範囲には、年産780万トンx 3系列のLNGプラントに加え、将来的な4系列目のLNGプラント増設に備える設備が含まれ ます。

当社はこれまでカタールで建設されたLNGプラント14系列の全てに携わり 、内12系列の 設計・調達・建設(EPC)業務を遂行しました。
70年代より石油・石油化学・ガス及び水処理設備等の多岐にわたる分野で、現地グループ企業である千代田アルマナエンジニアリング社(現地企業のアルマナグループと2008年に設立した当社49%出資の連結子会社 )とともに、現地顧客に対して100件を超えるプロジェクトを遂行してきました。

本受注は、このようなカタールにおける当社の絶え間ない貢献と実績が評価されたものです。
